Oliomio GOLD - Oliomio's newest olive oil extraction unit | Continuous Flow

Capacity up to 100kgs per hour | Avail Single or Three Phase
Call for price
Machine
Quantity

FAGOLD
  • Description
  • Features
  • Enquiry
  • Documents
Oliomio Gold is the ideal machine for producers who want to process their olives immediately after picking in order to obtain high-quality extra virgin olive oil.  The machine can process up to 90-100 kgs of olives per hour and is recommended for a daily production of approximately 700-800 kgs in 8 hours. It is equipped with a knife crusher, a horizontal continuous malaxer and with a new generation 2-phase decanter. The cleaning of the machine is completely automatic with a washing system installed on the malaxing tank manual intervention still required).

The machine is equipped with an inverter for the speed regulation showing revolutions of decanter/crusher, a flow-meter for dosage of water into the decater, a kit for washing the drum, a malaxer heating system temperature sensor, and a PLC control on the electrical panel, with a variator of revolutions of the screw feeding the paste to the decanter and a speed variator of revolutions of the screw feeding the olives to the machine, a kit for washing of the malaxer and with a PSS.1 waste discharge pump. Nozzles are adjustable.

With this new machine, Oliomio aims for simplicity in use and maintenance whilst achieving a high level of manipulation of the process with extra parameters not in other machinery.

Features:
  • A wide and clear control Panel
  • The washing system mounted on the machine is very simple and efficient, you can wash the machine simply opening the proper valves.
  • Every motor features variable speed.
  • Features further monitoring and control of paste and oil temperature with a PLC

It is recommended to combine with the Oliomio Gold :
  • Washer/deleafer DLE BABY
  • Stainless steel oil collector
  • Plate filter 20x20 (CPF.0).
Optional Extras (not included in the standard price):
  • PSS.1 waste pump
  • Pit remover attachment for crusher.


Minimum power 12 kW

Standard voltage:
  • Single Phase 220V 4 Kw 50 Hz. (3 poles - 16 Ampere SOCKET)
  • Three Phase 380V 4 kW 50 Hz. (5 poles - 16 Ampere SOCKET)
File Title File Description Type Section
Oliomio_Gold.pdf Oliomio GOLD Olive Oil Processing Unit Brochures Document
